P8.2 SMD Outdoor LED Display Screen
Features
1. P8.2 SMD outdoor LED display screen offers high efficiency, low energy consumption and is environmentally friendly.
2. It provides unrivalled peak brightness.
3. IP65 weatherproof.
4. Rugged, stylish design, easy to assemble and move.
5. The LED display screen achieves faithful reproduction of vivid colors by incorporating 16bit color control.
Application
Or Rishon Digital LED technology produces high-quality, high resolution images for a wide range of indoor and outdoor applications. Our P8.2 SMD outdoor LED display screen ensures superior image quality, color reproduction and uniformity even at extreme angles. Our newest generation products are adaptable to any shape and size, including convex, concave and curved screen configurations. With advanced image processing, our LED display screens are extremely stable and can accept a wide range of analog, digital, SD and HD inputs.
Technical Specifications
P8.2 SMD Outdoor Display
| Item | Unit | Parameters | Item | Unit | Parameters |
| Pixel pitch | mm | 8.2 | Cabinet Weight | kg/m2 | 65 |
| Pixel density | dots/m2 | 15626 | Brightness | cd/m2 | 6000 |
| Pixel configuration | SMD | 1R1G1B | Viewing angle (H/V) | Deg. | horizontal≥160°vertical≥160° |
| Module resolution | dot | 32×16 | Module size | mm | 262.4×131.2 |
| Power consumption | W/m2 | Max:750 Average:375 | Protection level | IP | 43 |
| Best viewing distance | m | 8-120 | LED life | Hours | ＞100,000 |
